We manufacture and supply KNG Plasform Panels, a modular plastic formwork system made from engineered polypropylene composite, offering a sustainable, reusable, and cost-efficient alternative to conventional plywood shuttering.
Certified as an Industrial Building System (IBS) and compliant with the Green Building Index (GBI), our Plasform is the first DIY (Do It Yourself) modular formwork system in India and the Asia-Pacific region. It is suitable for a wide range of applications in both sub-structure (footings, pile caps, ground beams, stumps) and super-structure (columns, walls, lift cores, beams, slabs).
In addition to the DIY system, manhandle and crane-handled configurations are also available, giving flexibility for projects of different scales.
Engineered for High Reuse and Cost Efficiency
KNG Plasform panels are designed to be reused over 200 times without degradation. After 200 uses, the effective cost becomes ₹20 per sq.m., the lowest in the market compared to plywood, aluminium, or steel shuttering systems.
- No swelling, shrinking, or disintegration over time
- No loss of surface finish even after prolonged usage
- No wastage or disposal issues—fully transferable between projects
- No release agents required due to non-stick surface
We also offer:
- Table Form Systems for large-span flat slabs
- Lift Core Formwork with Jump Platforms for vertical wall and core applications
| Side A (MM) | Side B (MM) | Weight (KG) |
| 600 | 1200 | 7.6 |
| 300 | 1200 | 3.9 |
| 250 | 1200 | 3.2 |
| 200 | 1200 | 2.6 |
| 150 | 1200 | 2.0 |
| 100 | 1200 | 1.5 |
Key Advantages of KNG Plasform Plastic Formwork
- Reusable across projects — No wastage unlike steel or aluminium systems
- Consistent high-quality concrete finish — Eliminates plastering requirement
- Reduces dependency on skilled labour
- Lighter in weight for ease of handling
- Ideal for both site-cast and precast construction
Physical Properties
- UV Resistant
- Impervious to water
- Non-swelling or shrinking
- Non-degradable
- Resistant to on-site construction chemicals
- Flexurally rigid and impact resistant
- Non-stick to concrete
- Self-weight: 10.6 kg/m²
Material Properties (Polypropylene)
- Elongation at Yield: 10%
- Heat Deflection Temperature: 85°C
- Rockwell Hardness: 82R Scale
- Water Absorption: 0.02%
Panel Design Data
- Allowable Bending at FoS(2.5): 0.45 kNm/m
- Allowable Shear: 13.6 kN
- Flexural Rigidity (EI): 2.1 kNm²/m
- Allowable Bearing Load on Panel: 500 kN/m²
- Allowable Shear in Pin: 0.68 kN
Performance at Site
- Smooth impervious PP surface reduces concrete adhesion
- Eliminates need for release agents
- Produces uniform and high-quality finish, reducing the risk of patchy surfaces
- Can withstand pouring pressure of 60 kN/m² for vertical concrete applications
Applications
Primary Applications
System Variants
